Pagoda Tent Series

Our Pagoda Tent Series features a high-strength aluminum frame (6005/T5) and double PVC-coated polyester fabric that is waterproof, flame retardant to DIN4102 and NFPA701, UV resistant, and suitable for temperatures from -30°C to 70°C. The standard side length is 5m with 2.3m side height, and sizes range from 3x3m to 10x10m. The maximum wind resistance is 80-100km/h. Optional accessories include wooden flooring, glass doors, glass walls, ABS walls, ground anchors, PVC-clear windows, rain gutters, decorative ceilings, and inside curtains. The tents have no interior poles for 100% usable space, are easy to set up and take down, and can be installed on any ground with expansion screws, steel nails, or weighting plates. PVC fabric life is approximately 5 years.

Pagoda tent structure detail drawing with aluminum frame and PVC cover    Pagoda tent outdoor installation for events and parties
Pagoda tent interior view with spacious open space    Pagoda tent for weddings, garden parties and special events
Pagoda tent side view showing multi-tiered roof design    Pagoda tent with optional accessories including flooring and lighting

Why Choose Our Pagoda Tents?

Unique Design: Our pagoda tents offer a distinctive and eye-catching design that will impress your guests.

Durability: Constructed with high-quality materials, our marquees are built to withstand various weather conditions.

Versatility: Ideal for weddings, parties, and special events, our pagoda tents can be customized to fit your specific needs.

Easy Setup: Our modular design allows for quick and easy assembly and disassembly.

Product Features:

Pagoda Style: The classic pagoda shape creates a timeless and elegant look.

Customizable Sizes: Choose from a variety of sizes to accommodate your guest list.

High-Quality Materials: Our marquees are made with premium-grade aluminum frames and durable PVC covers.

Customization Options: Choose from a variety of colors, flooring, lighting, and accessories.

Applications:

Weddings: Create a romantic and unforgettable wedding ceremony or reception.

Garden Parties: Host a beautiful outdoor party in your backyard.

Corporate Events: Make a lasting impression with a unique and elegant event space.

Cultural Celebrations: Celebrate your heritage with a traditional pagoda-style marquee.

Specifications:

Pagoda tent specification drawing showing frame and cover details

Pagoda tent specification drawing showing dimension details

Pagoda tent specification drawing showing assembly structure

Side Length/mSide Height/mTop Height/mProfile/mm
3X32.33.7φ63X2.5
4X44.3
5X54.5
6X64.9

Profile Type: Aluminum Profile 6005-T5, Anodized silver

Roof Cover: 650g/㎡ White Soft PVC with double sides coated fabric cover, (Option-Clear cover: 0.8 mm thickness transparent soft PVC); EN DIN 4102 B1, NFPA 701, waterproof, UV resistant, resistant temperature: -30 to +70℃

Side Wall: 650g/㎡ White Soft PVC with double sides coated fabric cover, (Option-Clear cover: 0.8 mm thickness transparent soft PVC); EN DIN 4102 B1, NFPA 701, waterproof, UV resistant, resistant temperature: -30 to +70℃

Color: White, Black, Red and Transparent as standard ones. More colors are available against request.

Brand Printing: Digital UV Printing

Fix Method: Weight blocks or Wind resistant cable and stakes

Options: Check details on Options Pages

Pagoda tent application scene for outdoor events and celebrations

Pagoda tent finished installation showing elegant multi-tiered roof

Frequently Asked Questions:

Q: Are pagoda tents waterproof?

A: Yes, our pagoda tents are completely waterproof, providing protection from the elements.

Q: Can I customize the color of the tent?

A: Yes, we offer a wide range of colors to choose from, like white, black, red, blue etc.

Q: How long does it take to set up a pagoda tent?

A: Setup time depends on the size and complexity of the tent, but our experienced team can complete most installations within a few hours.
